Products Detail
|
Model |
SH-PNL4065AD |
|
Physiscal Size |
65" |
|
Power |
< 240W |
|
standby power |
≤1Ｗ |
|
Display area |
1463*832mm |
|
Resolution |
1920x1080pixel, Max 3820*2160 |
|
Brightness |
450cd/m2 |
|
Viewing angle |
178 degree |
|
Packing parameters: |
|
|
External size (mm) |
1517*121*920mm |
|
Touch size (mm) |
1463*832mm |
|
Carton size (mm) |
1606*169*1071mm |
|
Net weight |
45kg |
|
Gross weight |
60kG |
|
ＴＶ information: |
|
|
TV Standard |
ATV(PAL/BG+DK)+DTMB |
|
Video Format |
MPEG1，MPEG2，MPEG4，H.264，RM，RMVB，AVI |
|
USB2.0 Multimedia Function |
Video/Audio/Photo/txt |
|
USB online upgrade |
Support USB Online Upgrade |
|
Resolution |
1920*1080,Max 3820*2160 |
|
Android System : |
|
|
CPU |
Cortex A53*3 1.4GHz |
|
RAM |
1 .0GMB DDR3 |
|
Android System |
Android 5.1 |
|
Function Description |
Support ONE key for Switch and ONE key for Power saving; |
|
Support writing function without PC; |
|
|
Support Smart Central controller, can switched any channel by touch; |
|
|
Support any Channel writing, Annotations, cleaning color, flip over and Gestures to zoom; |
|
|
Support Browsing; |
|
|
Support HD video play, support 1080P; |
|
|
support local and online Music Playing; |
|
|
Support Browning Multi format images; Support Office and other documents Browning and management; |
|
|
Support USB update software; |
|
|
Support Wi-Fi wireless |
|
|
OPS slot |
Yes |
|
Input and Output: |
|
|
HDMI format |
HDMI 2.0; HDCP 1.4 |
|
Scan method |
Support 1080i 1080P interlace progressive scan |
|
Audio Output |
2X12W |
|
Touch Panel Port |
2 Lines USB( Front 1 line type A and 1 line USB type B at the side of monitor) |
|
USB input port |
4 line USB 2.0 |
|
HDMI Input |
3 lines （1 lines outside ，1 line inside OPS 1 line front side） |
|
VGA Input |
1 line |
|
VGA output |
1 line |
|
VGA audio In |
1 line |
|
YABPR |
1 line |
|
PC Audio Input |
1 line |
|
AV Input |
1 line |
|
AV Output |
1 line |
|
RJ45 Input |
1 line |
|
Earphone Output |
1 line |
|
TF |
1 line |
|
RS232 |
1 line |
|
COAX/SPDIF Output |
1 line |
|
Touch parameters |
|
|
Touch technology |
Hybr Touch Distributed by DIR |
|
Multi touch points |
10 user can writing at the same time, 32 points |
|
Touch point |
10-user writing in Android OS, 10-user in Win7/Win8/Win10 |
|
Touch mode |
Multi touch |
|
Touch objects |
finger, pen or any other opaque objects |
|
Touch size |
Diameter≥7mm，Recommend≥７mm |
|
Resolution touch |
32768*32768 |
|
Responsible time |
First dot(click): 8ms, continuously(writing): 6ms |
|
Cursor speed |
up to 130 dots/s |
|
Operating life |
Unlimited |
|
Touch panel power |
USB power supply (4.6-5V,DC) |
|
Power |
≤1.5W |
|
Multi touch operation |
WIN7/WIN8/WIN10 |
|
Calibration: |
HID devices standard, accord with Win7 Win 8 multi-touch protocol, no need special software and could calibrate from Table PC setting under Win7/Win8 |
|
Anti-light decay function |
Anti-light decay circuits to prevent the performance degradation caused by long working hours |
|
Antilight interference function: |
can work properly in sunlight condition |
|
Certificate |
|
|
ISO9001, ISO14001, FCC, CE, CCC, Rohs |
ISO9001, ISO14001, FCC, CE, CCC, Rohs |
|
Standard Accessories |
|
|
Remote Control |
TV Remote control |
|
Power cable |
1.5m |
|
HDMI cable |
1.5m |
|
USB touch line |
3m |
|
Pen without ink |
1 Pcs |
|
Teaching pointer |
1Pcs |
|
User manual |
1 pcs |
|
Wall brackets |
1 set |
